Thermo Scientific Niton XL2 980 Plus

XL2 980 Plus General Metals XRF Analyzer for PMI and Alloy Verification
Metals verification can slow receiving, sorting, production, and quality control when alloy identity is uncertain. The Thermo Scientific Niton XL2 980 Plus handheld XRF analyzer with General Metals Option supports portable elemental analysis for PMI, alloy identification, scrap sorting, and metals verification without moving material to a lab.

General Metals XRF Analysis for Alloy Identification
Handheld X-ray fluorescence analysis helps confirm elemental composition directly at the material surface. The Niton XL2 980 Plus uses an Ag anode X-ray tube, silicon drift detector, and General Metals calibration mode to support point-and-shoot alloy and metals testing in industrial workflows.

General Metals calibration mode for metals and alloy verification
Analytical range from Mg to U for broad elemental coverage
8 mm collimation for controlled measurement spot size
Smart Fundamental Parameter calibration for matrix correction
Integrated CCD micro camera for locating and recording measurement positions

Portable Data Capture for PMI and Material Verification
Field and shop-floor testing often require traceable readings, stored results, and simple transfer into reporting workflows. The Niton XL2 Plus platform supports onboard storage, customizable data entry, and multiple communication methods for moving XRF results into documentation processes.

Stores approximately 10,000 readings with spectra
USB, Bluetooth, and RS-232 serial data transfer
Niton Data Transfer PC software support
Touchscreen keyboard with user-customizable data entry
Password-protected user security

Rugged Handheld Design for Industrial Metals Testing
Daily metals analysis depends on a portable form factor that can move between receiving areas, scrap yards, production floors, and inspection points. The Niton XL2 980 Plus combines a fixed-angle color resistive touchscreen, lithium-ion battery operation, and IP54 splash and dust protection for handheld XRF use across demanding material analysis environments.

IP54 splash and dust proof rating
3.4 lb handheld analyzer weight with battery
Fixed-angle color resistive touchscreen display
7.4V lithium-ion battery or 12V DC power supply operation
Built-in automatic system check for standardization

Specifications
MPN: XL2 980 PLUS
Product Condition: New
Shipping Length (in.): 22
Shipping Width (In.): 18
Shipping Height (In.): 12
Shipping Weight (lbs.): 25.00
Item Returns: This item can be returned
Description Niton XL2 Plus Handheld XRF Analyzer
Catalog Number XL2PLUS
Tube Voltage 6 to 45 kV
Weight 3.4 lbs with battery (1.53 kg)
Dimensions 10 x 10.8 x 3.9 in (25.6 x 27.5 x 10 cm)
X-Ray Source X-Ray Tube: Ag anode (6-45kV, 1-200uA, 2W max)
Detector Silicon drift detector (SDD)
Spot Size 8 mm collimation
Analytical Range Mg-U
Calibration Modes General Metals, Precious Metals, Coatings, Mining, Soils, Electronic Alloys, Plastics, Industrial Lead in Paint, Lead in Paint Products
Libraries Default alloy libraries based on SAE, AISI, ASTM, AA standards; users may create and edit libraries
System Check Built-in standardization via automatic system check
IP Rating IP54 (splash and dust proof)
Operating Environment Temperature: -10°C to 50°C; Humidity: 0% to 80% relative humidity non-condensing
Display Fixed angle, color, resistive touchscreen display
Power 7.4V lithium-ion battery, or 12V DC, 3A, 36W power supply
Camera Integrated CCD micro camera for locating and recording measurement positions
Global Positioning System Optional external GPS via Bluetooth
Bluetooth Supports print functionality, external GPS connectivity and barcode reader
Memory / Data Storage 64 MB internal system memory / 128 MB internal user storage; stores approximately 10,000 readings with spectra, fewer if images are saved
Data Entry Touchscreen keyboard; user customizable data entry; optional wireless remote barcode reader
Data Transfer USB, Bluetooth, and RS-232 serial communication
Operating System Proprietary
Support Software Niton Data Transfer (NDT) PC software
Security Password-protected user security
Languages English, Chinese, Spanish, Portuguese, Russian, Japanese, German, Korean, French, Italian, Czech
Compliance CE, RoHS, FCC, Industry Canada, Safety to IEC 61010-1, UL 61010-1
