Midas M32 Digital Mixer

Midas M32 Features:
World-class medium-format digital console for live sound and studio recording
I/O includes 40 input channels with 32 transparent, low-noise Midas preamps
Cirrus Logic converters and 40-bit floating point offer 112dB of dynamic range
Industry-leading ergonomic design by Rajesh Kutty of Bentley Motors
Channel controls and all major functions are always within easy reach
Master control section features a 7″ TFT display that’s easily viewable even in daylight
LCD and TFT displays across the board ensure that you’ll never get lost
Outfitted with 25 premium 100mm Midas Pro motorized faders rated to 1 million cycles
Easily assign channels to 8 DCA groups and 6 mute groups
Assign audio across 25 independent, time-aligned, and phase-coherent mix buses
100 Scenes/Snippets with 500 Cues provide powerful show automation possibilities
AES50 and Ultranet let you expand your system with P16 series personal mixers
Insert over 50 signal processors and effects across 8 stereo DSP engines
Simple USB port lets you record to a standard flash media drive
32-in/32-out, 48kHz USB 2.0 audio interface accommodates both studio and live recording
Control your DAW via either Mackie Control or HUI protocols with full automation
Optional Midas iOS apps provide Wi-Fi control via your iPhone or iPad
A perfect digital mixing console for touring sound reinforcement applications
Made of sturdy and lightweight carbon fiber, aluminum, and high-impact steel
Auto-ranging universal switch-mode power supply allows you to travel freely
32-channel live recording and playback on dual SD/SDHC cards
Independent operation of SD cards and USB recording/playback

Tech Specs
Type: Digital Mixer
Channels: 40
Inputs – Mic Preamps: 32 x XLR
Phantom Power: 48V, Switchable per Input
Inputs – Line: 1 x Dual RCA Stereo (aux)
Inputs – Other: 6 x 1/4″ TRS (aux)
Outputs – Main: 16 x XLR, 2 x XLR (monitor), 2 x 1/4″ (monitor)
Outputs – Other: 6 x 1/4″ TRS (aux), 1 x Dual RCA Stereo (aux)
Outputs – Digital: 1 x XLR (AES/EBU)
Busses/Groups: 25 time-aligned/phase-coherent mix buses, 8 DCA groups
Talkback: 1 x XLR
MIDI I/O: In/Out/USB
Data I/O: 1 x EtherCon (Ultranet), 2 x EtherCon (AES50), 1 x Ethernet
Headphones: 2 x 1/4″ TRS (stereo)
USB: 1 x Type B, 1 x Type A
Computer Connectivity: USB, Ethernet
Faders: 16 x Input Faders, 8 x Bus Faders, 1 x Main Fader
A/D Resolution: 24-bit/48kHz
EQ Bands: 4-band EQ
Effects: 8 x Stereo FX Engines
Signal Processing: Gate, Compressor
Features: 100-band RTA, 100 scenes, 100 Snippets, 32-bit/48kHz SD Card recording
DAW Control: Yes
Screen: 7″ TFT Display
Storage: 2 x SD card slots
Power Source: Standard IEC AC cable
Height: 10.1″
Depth: 24.1″
Width: 35.1″
Weight: 55 lbs.
Manufacturer Part Number: MIDAS-M32 LIVE
